Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  Thermoplastic Housing  > MUCFPL201RFB AMI

MUCFPL201RFB AMI

12MM STAINLESS SET SCREW RF BLACK 4-BOLT FLANGE
Item #: A85KX56955
Manufacturer: ASAHI - MOLINE INC.
155.16
Each
Quantity:
Quantity Price
1 155.16
A85KX56955

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Four Bolt Flange
Shaft Size
12 mm
Locking Device
Set Screw
Bolt Center
63.5 mm
Expansion Type
NON-EXP
Insert No.
MUC201RF
Overall length:
86 mm
Overall Height
36.3 mm
Base Height
13.4 MM
Seal Style
Dual Lip with Slinger
LTB
31 mm
Housing Config
Four Bolt Flange
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
1110 kgf
Static Load
540 kgf
Bolt Size
M10
Bearing Housing Material
PBT Thermoplastic
Weight
0.74 LB
