Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  4 Bolt Medium Duty  > UCF211-32NPMZ2 AMI

UCF211-32NPMZ2 AMI

2" MED ZINC WIDE SET SCREW NICKEL 4-BOLT FLANGE
Item #: A85KX08124
Manufacturer: ASAHI - MOLINE INC.
164.54
Each
Quantity:
Quantity Price
1 164.54
A85KX08124

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Four Bolt Flange
Shaft Size
2
Locking Device
Set Screw
Bolt Center
5-1/8"
Expansion Type
NON-EXP
Insert No.
UCX10-32MZ2
Overall length:
6-3/8"
Overall Height
2.299"
Base Height
25/32"
Seal Style
Contact with Slinger
LTB
2.189"
Housing Config
Four Bolt Flange
Roller Configuration
Ball Bearing
Duty Type
Medium Duty
Dynamic Load
9700 lbf
Static Load
6610 lbf
Bolt Size
5/8"
Bearing Housing Material
Cast Iron - Nickel Protection
Weight
7.04 LB
