Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  2 Bolt Flange  > UCFA202-10NP AMI

UCFA202-10NP AMI

20MM WIDE ACCU-LOC 2-BOLT FLANGE
Item #: A85KX049642
Manufacturer: ASAHI - MOLINE INC.
47.70
Each
Quantity:
Quantity Price
1 47.70
A85KX049642

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Two Bolt Flange
Shaft Size
0.625
Locking Device
Set Screw
Bolt Center
3-1/16"
Expansion Type
NON-EXP
Insert No.
UC202-10
Overall length:
4-1/64"
Overall Height
1.312"
Base Height
15/32"
Seal Style
Contact with Slinger
LTB
1.312"
Housing Config
TWO BOLT FLANGE
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
2890
Static Load
1500
Bolt Size
5/16"
Bearing Housing Material
Cast Iron NICKEL PLATED
Weight
1.12 LB
