Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Wide Slot  > UCST213C4HR5 AMI

UCST213C4HR5 AMI

65MM HIGH TEMP (400 DEG) WIDE SLOT TAKE-UP
Item #: A85KT11220
Manufacturer: ASAHI - MOLINE INC.
373.58
Each
Quantity:
Quantity Price
1 373.58
A85KT11220

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
65 mm
Locking Device
Set Screw
Bolt Center
136.5 mm
Insert No.
UC213C4HR5
Overall length:
223.8 mm
Overall Height
166.7 mm
Seal Style
Contact with Slinger
LTB
65.1 mm
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
27.0 mm
Dynamic Load
5850 kgf
Static Load
4100 kgf
Bearing Housing Material
Cast Iron
Slot Size.
WIDE
Weight
16.04 LB
