UCSTX11 AMI

55MM MEDIUM SET SCREW WIDE SLOT TAKE-UP
Item #: A85KT100162
Manufacturer: ASAHI - MOLINE INC.
165.77
Each
Quantity:
Quantity Price
1 165.77
A85KT100162

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
55 mm
Locking Device
Set Screw
Bolt Center
119.1 mm
Insert No.
UCX11
Overall length:
193.7 mm
Overall Height
146.1 mm
Seal Style
Contact with Slinger
LTB
65.1 mm
Housing Config
Take Up
Duty Type
Medium Duty
Slot Size
27.0 mm
Dynamic Load
5350 kgf
Static Load
3700 kgf
Bearing Housing Material
Cast Iron
Slot Size.
WIDE
Weight
10.92 LB
