UCAO306 AMI

30MM HEAVY SET SCREW PILLOW BLOCK
Item #: A85KZ24800
Manufacturer: ASAHI - MOLINE INC.
133.34
Each
Quantity:
Quantity Price
1 133.34
A85KZ24800

Mounted PB Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Pillow block
Shaft Size
30 mm
Locking Device
Set Screw
Shaft Centerline
47.6 mm
Insert No.
UC306
Overall length:
173 mm
Bolt Center Dim.
129 mm to 144 mm
Overall Height
96 mm
Seal Style
Contact with Slinger
LTB
43 mm
Housing Config
Pillow Block
Roller Configuration
Ball Bearing
Duty Type
Heavy Duty
Dynamic Load
2730 kgf
Static Load
1530 kgf
Bolt Size
M14
Base Width
49 mm
Bearing Housing Material
Cast Iron
Weight
4.08 LB
