Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  Piloted Flange  > UCME210 AMI

UCME210 AMI

50MM WIDE SET SCREW PILOTED FLANGE CARTRIDGE
Item #: A85KX65590
Manufacturer: ASAHI - MOLINE INC.
153.78
Each
Quantity:
Quantity Price
1 153.78
A85KX65590

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Piloted Flange
Shaft Size
50 mm
Locking Device
Set Screw
Bolt Center
95.5 mm
Bolt Circle
135 mm
Expansion Type
NON-EXP
Insert No.
UC210
Overall length:
165 mm
Overall Height
31.6 MM
Base Height
13 MM
Seal Style
Contact with Slinger
LTB
51.6 mm
Housing Config
Piloted Flange
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
3600 kgf
Static Load
2370 kgf
Bolt Size
M12
Bearing Housing Material
Cast Iron
Weight
0.76 LB
