Home  >  Bearings  >  Pillow Blocks  >  Ball Bearing  >  Tapped Base  > UCP310 AMI

UCP310 AMI

50MM HEAVY SET SCREW PILLOW BLOCK
Item #: A85KX44800
Manufacturer: ASAHI - MOLINE INC.
199.92
Each
Quantity:
Quantity Price
1 199.92
A85KX44800

Mounted PB Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Pillow block
Shaft Size
50 mm
Locking Device
Set Screw
Shaft Centerline
75 mm
Insert No.
UC310
Overall length:
275 mm
Bolt Center Dim.
194 mm to 232 mm
Overall Height
143 mm
Seal Style
Contact with Slinger
LTB
61 mm
Housing Config
Pillow Block
Roller Configuration
Ball Bearing
Duty Type
Heavy Duty
Dynamic Load
6300 kgf
Static Load
3900 kgf
Bolt Size
M16
Base Width
78 mm
Bearing Housing Material
Cast Iron
Weight
12.36 LB
