Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  2 Bolt Flange  > UCFT208-24 AMI

UCFT208-24 AMI

55MM NORMAL WIDE ADAPTER 2-BOLT FLANGE
Item #: A85KX20050
Manufacturer: ASAHI - MOLINE INC.
53.23
Each
Quantity:
Quantity Price
1 53.23
A85KX20050

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Two Bolt Flange
Shaft Size
1.5
Locking Device
Set Screw
Bolt Center
5-21/32"
Expansion Type
NON-EXP
Insert No.
UC208-24
Overall length:
6-3/4"
Overall Height
2.017"
Base Height
9/16"
Seal Style
Contact with Slinger
LTB
2.017"
Housing Config
TWO BOLT FLANGE
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
6590
Static Load
4020
Bolt Size
1/2"
Bearing Housing Material
Cast Iron
Weight
3.97 LB
