Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  Piloted Flange  > UGFCF211-35 AMI

UGFCF211-35 AMI

2-3/16" WIDE ECCENTRIC COLLAR PILOTED FLANGE CART
Item #: A85KX14136
Manufacturer: ASAHI - MOLINE INC.
154.18
Each
Quantity:
Quantity Price
1 154.18
A85KX14136

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Piloted Flange
Shaft Size
2.1875
Locking Device
Eccentric Collar
Bolt Center
6"
Expansion Type
NON-EXP
Insert No.
UG211-35
Overall length:
7-1/8"
Seal Style
Contact with Slinger
LTB
2-13/16"
Housing Config
Piloted Flange
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
9700 lbf
Static Load
6610 lbf
Bolt Size
9/16
Bearing Housing Material
Cast Iron
Weight
8.56 LB
