Home  >  Bearings  >  Flange Units  >  Ball Bearing  >  4 Bolt Standard Duty  > UCF215-47 AMI

UCF215-47 AMI

2-15/16" WIDE SET SCREW 4-BOLT FLANGE
Item #: A85KX08470
Manufacturer: ASAHI - MOLINE INC.
237.62
Each
Quantity:
Quantity Price
1 237.62
A85KX08470

Mounted 2 and 4 Bolt Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Four Bolt Flange
Shaft Size
2.9375
Locking Device
Set Screw
Bolt Center
6"
Expansion Type
NON-EXP
Insert No.
UC215-47
Overall length:
7-3/4"
Overall Height
3.209"
Base Height
15/16"
Seal Style
Contact with Slinger
LTB
3.063"
Housing Config
Four Bolt Flange
Roller Configuration
Ball Bearing
Duty Type
Normal Duty
Dynamic Load
14900 lbf
Static Load
10800 lbf
Bolt Size
3/4"
Bearing Housing Material
Cast Iron
Weight
18.28 LB
