Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Thermoplastic  > UCTPL203-11B AMI

UCTPL203-11B AMI

11/16" WIDE SET SCREW BLACK TAKE-UP
Item #: A85KT66030
Manufacturer: ASAHI - MOLINE INC.
70.88
Each
Quantity:
Quantity Price
1 70.88
A85KT66030

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
11/16"
Locking Device
Set Screw
Bolt Center
2-33/64"
Insert No.
UC203-11
Overall length:
3-57/64"
Overall Height
3-31/64"
Seal Style
Contact with Slinger
LTB
1.220"
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
15/32"
Dynamic Load
2890 lbf
Static Load
1500 lbf
Bearing Housing Material
PBT Thermoplastic
Weight
0.8 LB
