Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Thermoplastic  > UCNTPL208-24MZ2CEW AMI

UCNTPL208-24MZ2CEW AMI

1-1/2" ZINC WIDE SET SCREW WHITE TAKE-UP OPN/CLS
Item #: A85KT65220
Manufacturer: ASAHI - MOLINE INC.
137.48
Each
Quantity:
Quantity Price
1 137.48
A85KT65220

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
1-1/2"
Locking Device
Set Screw
Bolt Center
3-11/32"
Insert No.
UC208-24MZ2
Overall length:
5-33/64"
Overall Height
4-31/64"
Seal Style
Contact with Slinger
LTB
1.937"
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
1/4"
Dynamic Load
6590 lbf
Static Load
4020 lbf
Bearing Housing Material
PBT Thermoplastic
Slot Size.
Narrow
Weight
2.39 LB
