Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Thermoplastic  > UCNTPL207W AMI

UCNTPL207W AMI

35MM WIDE SET SCREW WHITE NARROW SLOT TAKE-UP
Item #: A85KT64510
Manufacturer: ASAHI - MOLINE INC.
106.57
Each
Quantity:
Quantity Price
1 106.57
A85KT64510

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
35 mm
Locking Device
Set Screw
Bolt Center
76 mm
Insert No.
UC207
Overall length:
125 mm
Overall Height
102 mm
Seal Style
Contact with Slinger
LTB
42.9 mm
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
6.4 mm
Dynamic Load
2640 kgf
Static Load
1570 kgf
Bearing Housing Material
PBT Thermoplastic
Slot Size.
Narrow
Weight
1.68 LB
