Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Wide Slot  > UCMST208MZ2RF AMI

UCMST208MZ2RF AMI

40MM ZINC SET SCREW RF STAINLESS WIDE SLOT TAKE-UP
Item #: A85KT57730
Manufacturer: ASAHI - MOLINE INC.
226.94
Each
Quantity:
Quantity Price
1 226.94
A85KT57730

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
40 mm
Locking Device
Set Screw
Bolt Center
88.9 mm
Insert No.
UC208MZ2RF
Overall length:
144.5 mm
Overall Height
114.3 mm
Seal Style
Dual Lip with Slinger
LTB
49.2 mm
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
17.5 mm
Dynamic Load
2990 kgf
Static Load
1830 kgf
Bearing Housing Material
304 Cast Stainless Steel
Slot Size.
WIDE
Weight
5.38 LB
