Home  >  Bearings  >  Take Up Units  >  Ball Bearing  >  Wide Slot  > UGST212 AMI

UGST212 AMI

60MM WIDE ECCENTRIC COLLAR WIDE SLOT TAKE-UP
Item #: A85KT13130
Manufacturer: ASAHI - MOLINE INC.
142.15
Each
Quantity:
Quantity Price
1 142.15
A85KT13130

Mounted TU Type

Manufacturer
ASAHI - MOLINE INC.
Housing Type
Take Up
Shaft Size
60 mm
Locking Device
Eccentric Collar
Bolt Center
119.1 mm
Insert No.
UG212
Overall length:
193.7 mm
Overall Height
146.1 mm
Seal Style
Contact with Slinger
LTB
77.8 mm
Housing Config
Take Up
Duty Type
Normal Duty
Slot Size
27.0 mm
Dynamic Load
5350 kgf
Static Load
3700 kgf
Bearing Housing Material
Cast Iron
Slot Size.
WIDE
Weight
11.08 LB
